Specifications:

Design: 2 Way Straight, 2 Way Angle, 3 Way 2 on Pressure, 3 Way 1 on Pressure & 3 Way 2 Stem Manifold 2-Ways Angle / Replaceable Seat

Rating: Up to 50,000 psi @ up to 1000ºF

Stem: Needle tip (Standard), Non routing (Optional)

Packing: Teflon™ & (Optional) Grafoil

Size: 1/8” to 1”

Connections: NPT, BSP, BSPT & Tube OD 1/8”, 1/4”, 3/8”, 1/2", 9/16 & 1”

Body: Forged Steel

Material: SS, CS and other Material on Request
